The Hysitron PI 88 SEM PicoIndenter is a comprehensive in-situ nanomechanical testing system for SEM, FIB/SEM and EBSD. In-situ nanoindentaiton, tensile, and bending experimetns can be performed. (Images from Bruker)
The in-situ tensile/compression tests can be carried out under SEM, EBSD and XRD. Testing temperature ranges from -150 to 800 oC. Nano-DIC can be performed under SEM.
Renowned for their unmatched accuracy, flexibility and high performance, MTS test systems provide all types of test including tension, compression, bending, fatigue, fracture toughness, etc.
HUALONG WDW-50C (Up to 50 KN) electromechanical testing machines offer force, displacement or deformation closed loop testing in tension, compression, flexure, shear, tear and peel etc.
HUALONG WAW-200 (Up to 200KN) Servo-hydraulic Universal Testing Machine is ideal for high-capacity tension, compression, bend/flex, and shear testing.
Hopkinson tensile bar for high strain rate tests up to 3000 s-1. Interrupted tensile test under high strain rate can be also carried out. Elevated or sub-zero temperature conditions can be applied on demand.
The Quenching/Deformation Dilatometer L78 RITA is especially suitable for the determination of TTT, CHT and CCT diagrams. The instrument can perform measurements under vacuum, inert, oxidized, reduced atmospheres.
Thermal Analysis platform
It allows thermogravimetric analysis (TGA) and simultaneous thermal analysis (STA) to be performed. They are crucial in the study of thermal behavior of materials, such as thermal stability and sintering temperatures of metal powders. (shared from ME dept)
Bruker G4 Phoenix TDS for measuring hydrogen content in metals with an accuracy of 0.1 ppm. This is an essencial facilty for studying the hydrogen embrittle or delayed fracture of adcanced high strength steels.
The PARSTAT 3000A-DX Bipotentiostat combines 2 high performance, independent potentiostats with floating capability in a single chassis. Studies of corrosion and hydrogen embrittlement can be performed.
The Proof Ring test systems are broadly used to study stress corrosion cracking and hydrogen embrittlement research. Constant load test can be carried out under ambient conditions or with an environmental chamber. Different types of specimens could be tested with these proof rings to fulfill other demanding requirements.
The SmartLab is the most novel high-resolution X-ray diffractometer available today. SmartLab employs a new rotating anode X-ray generator that is specifically optimized for the optics and geometries, allowing SmartLab to achieve three times higher intensity than current products (shared from ME Dept).
High resolution SEM with EDS, BSE, EBSD (very fast Oxiform Symmetry ). Transimisison EBSD can be performed. In-situ nanoindentaion, in-situ tensile test can be carried out in this system. (shared from ME Dept)
Observe uncoated samples by beam deceleration option; In-lens SE and BSE detection at low voltages; EDS system for elemental analysis and mapping. (shared from EMU)
In-lens annular detector for bright, clear surface-specific image; EDS system for elemental analysis and mapping; EBSD system also includes for the microtexture determination. (shared from EMU)
Tecnai G2 20 S-TWIN is ready for new applications like EDS with mapping, STEM. The system has a high diffraction acceptance angle, which makes it suitable for tilting and other analytical experiments. (shared from EMU)
Transmission Electron Microscope
It allows high-resolution STEM and TEM imaging, as well as EDX operations for 2D/3D chemical characterization and mapping. (shared from EMU)
DualBeam Focus Ion Beam
For the materials science lab it offers the capability of in-situ dynamic experiments, 3D imaging and analysis and TEM sample preparation for more in-depth analysis. (shared from EMU)
Atomic Force Microscope
It offers PeakForce Tapping, PeakForce QNM, PeakForce KPFM, PeakForce TUNA, etc. (shared from ME dept)
